DIN 41612 3 Rows Eurocard Connector Male 90 Degree R/A Board Lock PCB

96Pin 2.54mm pitch R/A PCB 3 rows DIN41612 Connector, Right Angle PCB 3*32 96 pin DIN 41612 Euro Male Connector with Board Lock

3 rows DIN41612 Connector Male 90 Degree R/A PCB Euro 41612 Connector

DIN 41612.pdf

DIN 41612 is a DIN standard for electrical connectors that are widely used in rack-based electrical systems. Standardization of the connectors is a prerequisite for open systems, where users expect components from different suppliers to operate together. The most widely known use of DIN 41612 connectors is in the VMEbus system.

The DIN 41612 has been widely accepted as a standard for a variety of interconnection applications in the telecommunications and data markets worldwide. The most widely known use of DIN 41612 connectors is in the VME bus system. DIN connectors with three rows (a, b, c) of contacts on 0.100" (2.54mm) square grid are available in wire-wrap or solder tail type terminations. 5pin, 10pin, 15pin, 20pin, 30pin, 32pin, 48pin, 64pin and 96pin are available.

PRODUCT SPECIFICATIONS

• DIN 41612 Two-Part Connectors for Printed Circuit Boards
• IEC 60603-2 Connectors for Frequencies below 3 MHz for Printed Circuit Boards

APPLICATION SPECIFICATIONS

• 114-9014 Eurocard Connector Types B, C, M and R (Board-to-Board Application)
• 114-19004 Eurocard Connector, Type F Receptacle
• 114-12026 Type M Coax Contacts
• 114-10014 Size VIII Power Contacts
