68 pin SCSI Connector, Male Type, 68pin MDR Connector

Large Image : 68 pin SCSI Connector, Male Type, 68pin MDR Connector

Product Details:

Place of Origin:	China
Brand Name:	FUYCONN
Model Number:	SCSI Connector

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	USD0.2-USD2/pc
Packaging Details:	Vacuum Tray + Carton
Delivery Time:	5-8 works day
Payment Terms:	T/T, Paypal
Supply Ability:	100000/ week

Contact Now

68 pin SCSI Connector, Male Type, 68pin MDR Connector

Description

Product Name:	SCSI Connector	Product Line:	MDR Connector
Insulation Material:	PBT	Pitch:	1.27 Mm
Connector Type:	PCB / IDC / Solder Type	No. Of Contact:	14/24/36/5068/100 Pin
Gender:	Female / Male
Highlight:	MDR PCB SCSI Connector , Phosphore Bronze SCSI Connector , 100Pin MDR Connector

PCB SCSI Connector 14pin 26pin 36pin 50pin 68pin 100Pin MDR Connector

Catalog: SCSI CONNECTOR.pdf

SCSI (Small Computer System Interface) Servo Connector, is a kind of more special interface bus, equipped with a variety of types of peripherals to communicate. Advanced High Speed A versatile, high-speed, and low-cost method of interconnecting a varietyof computer peripherals and consume electronic devices.

The SCSI Connector (MDR Mini D Ribbon) are 14pin, 20pin, 26pin, 36pin, 50pin, 68pin and 100pin, and PCB / IDC Crimping type SCSI Connector versions. The internal 100 pin SCSI connector has 100 pins arranged in two rows one on top of the other. The top row has 0 pins and the lower row has 50 pins

Product features

1. Product Line:	SCSI Connector
2. Connector Gender:	Male
3. Number of Position:	68 pin
4.Insulator:	PBT
5. Contact Material:	Phosphore Bronze
6. Contact Plating:	1U", 3U", 5U", 10U", 15U",30U"
7. Color	Black
8. Application:	Cable

Electrical Specifications

Current Rating	1AMP
Withstanding Voltage	500v for one minute
Insualtion Resistance	500MΩ min (at DC500V)
Contact Resistance	35MΩ Max)
Operating temperature :	-55°C to +105°C

Technology Parameters

68 pin SCSI Connector, Male Type, 68pin MDR Connector 0
