IEEE 488 GPIB Connector , Male Female 24pin IEEE 488 Connector

Catalog: CENTRONIC CONNECTOR.pdf

The Centronics connector features a plastic bar in the center of the connector body that holds the contact pins. The connector body is typically black or blue in color. Both male and female Centronics connectors are available. Male Centronics connectors have side latches that snap into tabs on the sides of female connectors. Female connectors also have slots to receive pins from male connectors. Typically, Centronics connections consist of a 36-pin male or female connector at the printer or other peripheral, a cable, and a 25-pin parallel port on the computer. Centronics connectors use eight parallel data lines, as well as other lines to read status information and send control signals.

The Centronics 24-pin connector is arranged in two rows of pins, each with 12 contacts. The connector is held in place by bail locks. The 36-pin connector is often used for parallel applications, especially for printers. It is also referred to as an IEEE-1284 Type B connector.

• ROHS compliant, UL-approved
• High quality, Competitive price
• Quick delivery time
• Free sample available in 2 days

• Designed for Cable-to-cable and cable-to-PC Board applications
• Board Application
• Available in Plug & Socket styles
• Terminal Option with various types
• Connector and hood sold as complete assembly
• Available in low profile hood style
• Metal shell provides grounding and shielding capability
• Mates with industry compatible connector

• VDSL Telecom Equipment
• Computer Peripherals
• Communication Equipment
• PCB Board
• Cable to Panel
• Cable to cable
• Computer terminal
• Telemetering
• Test Equipment
• Printer
