Centronics Male 24pin IEEE488 Connector Vertical PCB 2.16mm With Black Screws

Large Image : Centronics Male 24pin IEEE488 Connector Vertical PCB 2.16mm With Black Screws

Product Details:

Place of Origin:	China
Brand Name:	FUYCONN
Certification:	UL 94-V0, ROHS-certified, ISO 9001:2008, ISO 14001:2004
Model Number:	FUY57018C-24P

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiable
Packaging Details:	Vacuum Tray + Carton
Delivery Time:	7-10 days
Payment Terms:	T/T or Paypal
Supply Ability:	1 million/ month

Contact Now

Centronics Male 24pin IEEE488 Connector Vertical PCB 2.16mm With Black Screws

Description

Connector Line:	Centronic Connector	Connector Type:	DDK Connector
Pin No.:	24pin	Gender:	Male Centronic Connector
Contact Type:	PCB Right Angle	Pitch:	2.16mm
Insulation Material:	PBT	Contact Material:	Brass
Highlight:	24pin Centronics IEEE488 Connector , 2.16mm Centronics IEEE488 Connector , Black Screws Centronics Connector

Centronics Male 24pin IEEE488 Connector Vertical PCB 2.16mm With Black Screws

Product Overview

24pin IEEE488 Connector Vertical PCB 2.16mm Centronics Male Connector with Black Screws. The Centronics connector features a plastic bar in the center of the connector body that holds the contact pins, typically in black or blue color. Both male and female Centronics connectors are available with side latches that snap into tabs for secure connection.

Download Product Catalog (PDF) Centronics 24-pin IEEE488 connector showing pin configuration and black screws

Key Advantages

ROHS compliant, UL-approved
High quality, competitive pricing
Quick delivery time
Free samples available within 2 days

Product Specifications

Product Line	Centronic Connector
Product Name	PCB 57 Connector
Connector Gender	Male Centronic Connector
Number of Positions	24pin
Contact Material	Phosphor Bronze
Contact Plating	1U", 3U", 5U", 10U", 15U", 30U"
Insulation Material	PBT
Color	Black or Blue
UL Flammability Rating	UL-94-V0
Certification	UL Certificated
Shell	Nickel plated steel
Connector Type	PCB Right Angle
Pitch	2.16mm pitch
PCB Mounting	L Plated

Common Features

Designed for cable-to-cable and cable-to-PC board applications
Suitable for board applications
Available in plug & socket styles
Terminal options with various types
Connector and hood sold as complete assembly
Available in low profile hood style
Metal shell provides grounding and shielding capability
Mates with industry compatible connectors

Material Composition

Contact Material	Phosphor Bronze
Insulator	PBT (UL 94-V0)
Shell	Nickel Plated Steel

Electrical Characteristics

Current Rating	5Amp
Withstanding Voltage	AC 1000v r.m.s
Insulation Resistance	1000 Megohms Minimum at DC 500V
Contact Resistance	25MΩ Max Mated
Operation Temperature	-55°C to +105°C

Applications

VDSL Telecom Equipment
Computer Peripherals
Communication Equipment
PCB Board
Cable to Panel
Cable to cable
Computer terminal
Telemetering
Test Equipment
Printer
